Brief Description of the Process Flow of a Cold Extrusion Hydraulic Press for Automotive Parts

The basic working principle of an automotive parts cold extrusion hydraulic press is based on Pascal's Law. The hydraulic system converts the mechanical energy of an electric motor into the pressure energy of a liquid, which is then converted into linear motion mechanical energy by the actuator (main cylinder) to extrude the billet. Below is a brief description of the machine's process flow from Jianlong Hydraulic Technology for your reference!

1. Material Preparation: Coiled steel is cut into fixed-length billets using a precision shearing machine.

2. Softening Annealing (Optional) & Surface Treatment: The billets are annealed to reduce hardness and undergo phosphating-saponification treatment to form a lubricating layer on the surface, reducing friction and die wear.

3. Loading: The treated billets are placed into the lower die of the cold extrusion hydraulic press.

4. Extrusion Forming:

4.1 The movable crossbeam (slider) moves downwards under the drive of the main cylinder.

4.2 The upper and lower dies close, applying significant pressure to the billet.

4.3 Under pressure, the metal billet undergoes plastic flow, filling the mold cavity to form the part.

5. Ejection and Demolding: After forming, the movable crossbeam returns, and the ejector device ejects the part from the mold.

6. Post-processing: Subsequent processes such as trimming, drilling, and finishing are performed.

Automotive parts cold extrusion hydraulic presses are indispensable key equipment in the modern automotive industry, especially in the manufacturing of high-end and new energy vehicles. For more information/advice on automotive parts cold extrusion hydraulic presses or to purchase other high-quality hydraulic presses, please contact us (or scan the WhatsApp QR code below). Jianlong Hydraulic Technology will provide you with personalized and customized professional solutions and is dedicated to serving you.
